F

E50.U*** SR17 TM
DC
750…3600V DC

CAPACITORS WITH A CAN DIAMETER OF 142 and 172 mm
Design F Can material ....................................stainless steel with welded lid

F Terminal torque
F3 (M12) ......................................14 Nm
Da d F5/F7 (M16) .................................25 Nm
I max (Terminals)
13 M12 ..............................................80 A
M16 ..............................................200 A
90...105 Degree of protection .......................IP 00

h K ...................................................43 mm
L ...................................................30 mm
Humidity class.................................C, TX (IEC 62498-1)

KONDENSATOREN MIT GEHÄUSEDURCHMESSER 142 und 172 mm
Gehäusematerial ..............................Edelstahl, eingeschweißter Deckel
L 1 Anschlußdrehmoment
F3 (M12) .......................................14 Nm
F5/F7 (M16) ..................................25 Nm
I max (Anschlüsse)
M12 ...............................................80 A
M16 ...............................................200 A
Schutzgrad ........................................IP 00
K ...................................................43 mm
D 1 L ....................................................30 mm
Feuchteklasse ..................................C, TX (IEC 62498-1)

bracket 95
Winkel 40

DATA CHARTS_DATENTABELLEN_SR17 TM
Design h

F3/F5 30
2
F7 53

a (±2)
D 1
172.5 100
a 142 60
116 60

26
