E57.A12 (Substitute LNK-P5X)
DC
650 … 4200V DC

Dimension Drawings Maßbilder

61 122 61 M10×25
xx = 20 61 122 61 M10×25 27
27

235
235
15
15
150
150
460
460 resin
resin

380 Clearance in air Luftstrecke 45 mm
380 Creepage distance Kriechstrecke 45 mm

160 38 38
38
160 160
xx = 10 12,5 12,5 12,5 120 60 15
120 120
15 15
60 60
235 235 260 260 235 260

1515 15
150
150 150
460
460 460
resin
resin resin

Clearance in air Luftstrecke 38 mm
Creepage distance Kriechstrecke 38 mm
380
380 380 TECHNICAL DRAWINGS_MASSBILDER_E57.A12

Can material ............................ glas-fibre reinforced plastic, UL94-V0 Gehäusematerial .................... glasfaserverstärkter Kunststoff UL94-V0
Terminals xx=10 .............. tinned copper bars Anschlüsse xx=10 .............. Kupferschienen, verzinnt
xx=20 .............. threaded studs, tinned brass M10 × 25 xx=20 .............. Gewindebolzen, Messing verzinnt M10 × 25
I max (Terminals) xx=10 .............. 300 A I max (Terminals) xx=10 .............. 300 A
xx=20 .............. 160 A xx=20 .............. 160 A
Degree of Protection .............. IP00 Schutzgrad .............................. IP00
